The K8s Source plugin for CloudQuery extracts configuration from a variety of K8s APIs

Publisher

cloudquery

Latest version

v7.7.0

Type

Source

Platforms

Date Published

Overview #

The K8s Source plugin for CloudQuery extracts configuration from a variety of K8s APIs.

Libraries in Use #

Authentication #

Similar to how kubectl works, cloudquery depends on a Kubernetes configuration file to connect to a Kubernetes cluster and sync its information. By default, cloudquery uses the default Kubernetes configuration file (~/.kube/config). You can also specify a different configuration by setting the KUBECONFIG environment variable before running cloudquery sync.
export KUBECONFIG="<PATH_TO_YOUR_CONFIG_FILE>"

Kubernetes Service Account #

If cloudquery is running in a pod of the Kubernetes cluster, the Kubernetes Service Account can be used for direct authentication. To use the Kubernetes Service Account for direct authentication, a cluster role with all get and list privileges will need to be used.
The below command creates a new cluster role with get and list privileges.
kubectl apply -f - <<EOF
apiVersion: rbac.authorization.k8s.io/v1
kind:       ClusterRole
metadata:
  name: cloudquery-cluster-read
rules:
- apiGroups:
  - '*'
  resources:
  - '*'
  verbs:
  - get
  - list
- nonResourceURLs:
  - '*'
  verbs:
  - get
  - list
EOF
Next, the cluster role and service account will need to be linked via a cluster role binding. The following creates a cluster role binding for the role we created above and the service account for the cloudquery pod.
kubectl apply -f - <<EOF
apiVersion: rbac.authorization.k8s.io/v1
kind:       ClusterRoleBinding
metadata:
  name: cloudquery-cluster-read-binding
subjects:
- kind: ServiceAccount
  name: cloudquery-sa
roleRef:
  kind: ClusterRole
  name: cloudquery-cluster-read
EOF


Configuration #

K8s Source Plugin Configuration Reference

The K8s source plugin connects to a Kubernetes cluster, fetches resources and loads it into any supported CloudQuery destination (e.g. PostgreSQL, BigQuery, Snowflake, and more).

Example #

This example connects a single k8s context to a Postgres destination. The (top level) source spec section is described in the Source Spec Reference.
kind: source
spec:
  # Source spec section
  name: k8s
  path: cloudquery/k8s
  registry: cloudquery
  version: "v7.7.0"
  tables: ["*"]
  destinations: ["postgresql"]
  # Learn more about the configuration options at https://cql.ink/k8s_source
  spec:
    contexts: ["context"]
This example connects to an EKS cluster using an IAM role. Provider spec is used to generate a kube config file for the provider. The (top level) source spec section is described in the Source Spec Reference.
kind: source
spec:
  name: k8s
  path: cloudquery/k8s
  version: v7.3.8
  tables:
    - "*"
  spec:
    providers:
     - cluster: eks-cluster-name
       aws:
         region: us-east-1
         role_arn: arn:aws:iam::111111111111:role/cross-account-readonly-role
This example connects to an AKS cluster using a service principal. For more details on creating the service principal see our Azure source plugin docs. The (top level) source spec section is described in the Source Spec Reference.
kind: source
spec:
  name: k8s
  path: cloudquery/k8s
  version: "v7.7.0"
  tables:
    - "*"
  spec:
    providers:
      - cluster: cluster-name
        azure:
          # service principal details:
          client_id: service-pricipal-app-id
          tenant_id: service-pricipal-tenant
          client_secret: service-pricipal-password
          # k8s cluster details:
          subscription_id: subscription-id
          resource_group_name: resource-group-name
This example connects to a GKE cluster using a Service Account JSON key.
kind: source
spec:
  name: k8s
  path: cloudquery/k8s
  version: "v7.7.0"
  tables:
    - "*"
  spec:
    providers:
     - cluster: gcp-cluster-name
       gcp:
         project_id: project-id
         location: us-central1
         service_account_key_json: |
          ${SERVICE_ACCOUNT_JSON_KEY}
         authenticate_gcloud: true

K8s Spec #

This is the (nested) spec used by K8s Source Plugin
  • contexts ([]string) (optional) (default: empty. Will use the default context from K8s's config file)
    Specify K8s contexts to connect to. Specifying * will connect to all contexts available in the K8s config file (usually ~/.kube/config).
  • concurrency (integer) (optional) (default: 5000)
    A best effort maximum number of Go routines to use. Lower this number to reduce memory usage.
  • scheduler (string) (optional) (default: dfs) The scheduler to use when determining the priority of resources to sync. Supported values are dfs (depth-first search), round-robin, shuffle and shuffle-queue.
    For more information about this, see performance tuning.
  • providers ([]Provider) (optional) (default: empty.)
    List of providers to connect to. This is used to generate a kube config file for the provider. Each entry in the list represents a context in the K8s config file and first entry is the default context. Cluster name is the name of the context in the K8s config file also.

Provider Spec #

  • cluster (string) (required)
    Name of the cluster.
  • aws (AWSSpec) (optional)
    AWS specific configuration for EKS cluster access
  • gcp (GCPSpec) (optional)
    GCP specific configuration for GKE cluster access
  • azure (AzureSpec) (optional)
    Azure specific configuration for AKS cluster access

AWSSpec #

  • region (string) (required)
    Region of the EKS cluster.
  • role_arn (string) (optional)
    IAM Role ARN to assume to access the EKS cluster.
  • external_id (string) (optional)
    ExternalID to use when assuming the IAM Role.

GCPSpec #

  • project_id (string) (required)
    Project of the GKE cluster.
  • location (string) (required)
    Location of the GKE cluster.
  • service_account_key_json (string) (required)
    Service account key, generated from GCP
  • authenticate_gcloud (bool) (optional)
    If set, the plugin will use the provided Service Account JSON to authenticate. Analogical to running gcloud auth activate-service-account --key-file=<JSON_FILE>

AzureSpec #

  • subscription_id (string) (required)
    Azure subscription ID where the cluster is defined.
  • resource_group_name (string) (required)
    Azure resource group name of the cluster.
  • client_id (string) (required)
    Azure client ID or the service principal app ID.
  • tenant_id (string) (required)
    Azure tenant ID.
  • client_secret (string) (optional)
    Azure secret or the service principal password.
  • oidc_token (string) (optional)
    Azure OIDC token. Use this option when not using the client_secret.
  • cloud_name (string) (optional)
    The name of the cloud environment to use. Possible values are AzureCloud, AzureChinaCloud, AzureGovernment.

Example #

This example connects a single k8s context to a Postgres destination. The (top level) source spec section is described in the Source Spec Reference.
kind: source
spec:
  # Source spec section
  name: k8s
  path: cloudquery/k8s
  registry: cloudquery
  version: "v7.7.0"
  tables: ["*"]
  destinations: ["postgresql"]
  # Learn more about the configuration options at https://cql.ink/k8s_source
  spec:
    contexts: ["context"]
This example connects to an EKS cluster using an IAM role. Provider spec is used to generate a kube config file for the provider. The (top level) source spec section is described in the Source Spec Reference.
kind: source
spec:
  name: k8s
  path: cloudquery/k8s
  version: v7.3.8
  tables:
    - "*"
  spec:
    providers:
     - cluster: eks-cluster-name
       aws:
         region: us-east-1
         role_arn: arn:aws:iam::111111111111:role/cross-account-readonly-role
This example connects to an AKS cluster using a service principal. For more details on creating the service principal see our Azure source plugin docs. The (top level) source spec section is described in the Source Spec Reference.
kind: source
spec:
  name: k8s
  path: cloudquery/k8s
  version: "v7.7.0"
  tables:
    - "*"
  spec:
    providers:
      - cluster: cluster-name
        azure:
          # service principal details:
          client_id: service-pricipal-app-id
          tenant_id: service-pricipal-tenant
          client_secret: service-pricipal-password
          # k8s cluster details:
          subscription_id: subscription-id
          resource_group_name: resource-group-name
This example connects to a GKE cluster using a Service Account JSON key.
kind: source
spec:
  name: k8s
  path: cloudquery/k8s
  version: "v7.7.0"
  tables:
    - "*"
  spec:
    providers:
     - cluster: gcp-cluster-name
       gcp:
         project_id: project-id
         location: us-central1
         service_account_key_json: |
          ${SERVICE_ACCOUNT_JSON_KEY}
         authenticate_gcloud: true
