Overview #

ClickHouse source plugin

The CloudQuery ClickHouse plugin syncs your ClickHouse database to any of the supported CloudQuery destinations (e.g. PostgreSQL, BigQuery, Snowflake, and more).

Supported database versions: >= 24.2

Configuration #

Example #

kind: source
spec:
  name: "clickhouse"
  path: "cloudquery/clickhouse"
  registry: "cloudquery"
  version: "v1.2.25"
  destinations: ["postgresql"]
  tables: ["*"]
  # Learn more about the configuration options at https://cql.ink/clickhouse_source
  spec:
    connection_string: "clickhouse://${CH_USER}:${CH_PASSWORD}@localhost:9000/${CH_DATABASE}"
    # Optional parameters
    # ca_cert: ""
    # rows_per_record: 500
    # concurrency: 100
    # table_options:
    #   test_table:
    #     incremental_column: "created_at"

This example configures sync from a ClickHouse instance, located at localhost:9000. It expects CH_USER, CH_PASSWORD and CH_DATABASE environment variables to be set. The (top level) spec section is described in the Source Spec Reference.

Make sure you use environment variable expansion in production instead of committing the credentials to the configuration file directly.

ClickHouse spec #

This is the (nested) spec used by the ClickHouse source plugin.

connection_string (string) (required)
Connection string to connect to the database. See SDK documentation for more details.
ca_cert (string) (optional) (default: not used)
PEM-encoded certificate authorities. When set, a certificate pool will be created by appending the certificates to the system pool.
See file variable substitution for how to read this value from a file.
rows_per_record (integer) (optional) (default: 500)
Amount of rows to be packed into a single Apache Arrow record to be sent over the wire during sync.
concurrency (integer) (optional) (default: 100)
Number of tables to sync concurrently. Lower or increase this number based on your database size and available resources.
table_options (object) (optional) (default: not used)
Table options to set an incremental column.

Connecting to ClickHouse Cloud #

To connect to ClickHouse Cloud, you need to set the secure=true parameter, username to default, and the port to 9440. Use a connection string similar to:

    connection_string: "clickhouse://default:${CH_PASSWORD}@<your-server-id>.<region>.<provider>.clickhouse.cloud:9440/${CH_DATABASE}?secure=true"

See Quick Start: Using the ClickHouse Client for more details.

Verbose logging for debug

The ClickHouse source can be run in debug mode. To achieve this pass the debug=true option to connection_string. See SDK documentation for more details.

Note: This will use SDK built-in logging and might output data and sensitive information to logs. Make sure not to use it in production environment.

kind: source
spec:
  name: "clickhouse"
  path: "cloudquery/clickhouse"
  registry: "cloudquery"
  version: "v1.2.25"
  tables: ["*"]
  spec:
    connection_string: "clickhouse://${CH_USER}:${CH_PASSWORD}@localhost:9000/${CH_DATABASE}?debug=true"

Types #

Apache Arrow type conversion #

The ClickHouse source plugin supports most of ClickHouse data types. It uses the same approach as documented in ClickHouse reference. The following table shows the supported types and how they are mapped to Apache Arrow types.

Unsupported types are always mapped to String.

ClickHouse Type	Arrow Column Type
Bool	Boolean
UInt8	Uint8
UInt16	Uint16
UInt32	Uint32
UInt64	Uint64
Int8	Int8
Int16	Int16
Int32	Int32
Int64	Int64
Float32	Float32
Float64	Float64
String	String
FixedString	Fixed Size Binary
Date32	Date32
DateTime	Timestamp
DateTime64	Timestamp
Decimal	Decimal128 (Decimal) or Decimal256 based on precision
Array	List
Map	Map
Tuple	Struct
UUID	UUID (CloudQuery extension)

Nested ClickHouse types have their values converted according to the aforementioned rules.
