Overview #

DuckDB Destination Plugin

This destination plugin lets you sync data from a CloudQuery source to a DuckDB database.

Example Config #

This is a basic configuration that will save all your sync resources to ./database.db in the local directory.

kind: destination
spec:
  name: duckdb
  path: cloudquery/duckdb
  registry: cloudquery
  version: "v6.2.1"
  write_mode: "overwrite-delete-stale"
  # Learn more about the configuration options at https://cql.ink/duckdb_destination
  spec:
    connection_string: ./database.db
    # Optional parameters
    # batch_size: 1000
    # batch_size_bytes: 4194304 # 4 MiB
    # debug: false

After running cloudquery sync, you can explore the data locally with the DuckDB CLI: duckdb ./database.db.

The default write_mode is overwrite-delete-stale, but the plugin also supports overwrite or append. Note that overwrite and overwrite-delete-stale modes do not support atomic updates: to update a resource, it is first deleted and then re-inserted. This is due to a current lack of support in DuckDB for upserting list-type columns. If this is an issue for you, consider using the append mode instead. You may then perform a manual cleanup of stale resources after the sync completes.

Note that this plugin does currently not support Windows. See this issue for more details.

DuckDB Spec #

This is the top level spec used by the DuckDB destination Plugin.

connection_string (string) (required)
Absolute or relative path to a file, such as ./example.duckdb.
batch_size (integer) (optional) (default: 1000)
Maximum number of items that may be grouped together to be written in a single write.
batch_size_bytes (integer) (optional) (default: 4194304 (4 MiB))
Maximum size of items that may be grouped together to be written in a single write.
debug (boolean) (optional) (default: false)
Enables debug logging.

Types #

The DuckDB destination supports most Apache Arrow types. The following table shows the supported types and how they are mapped to DuckDB data types.

Unsupported types are always mapped to varchar.

Arrow Column Type	Supported?	DuckDB Type
Binary	✅ Yes	`blob`
Boolean	✅ Yes	`boolean`
Date32	✅ Yes	`timestamp`
Date64	✅ Yes	`timestamp`
Decimal	✅ Yes	`varchar`
Dense Union	✅ Yes	`varchar`
Dictionary	✅ Yes	`varchar`
Duration	✅ Yes	`varchar`
Fixed Size List	✅ Yes	`varchar`
Float16	✅ Yes	`varchar`
Float32	✅ Yes	`float`
Float64	✅ Yes	`double`
Inet	✅ Yes	`varchar`
Int8	✅ Yes	`tinyint`
Int16	✅ Yes	`smallint`
Int32	✅ Yes	`integer`
Int64	✅ Yes	`bigint`
Interval[DayTime]	✅ Yes	`varchar`
Interval[MonthDayNano]	✅ Yes	`varchar`
Interval[Month]	✅ Yes	`varchar`
JSON	✅ Yes	`json`
Large Binary	✅ Yes	`blob`
Large List	✅ Yes	Array of element type
Large String	✅ Yes	`varchar`
List	✅ Yes	Array of element type
MAC	✅ Yes	`varchar`
Map	✅ Yes	`varchar` †
String	✅ Yes	`varchar`
Struct	✅ Yes	`varchar` †
Timestamp	✅ Yes	`timestamp`
UUID	✅ Yes	`uuid`
Uint8	✅ Yes	`uinteger`
Uint16	✅ Yes	`uinteger`
Uint32	✅ Yes	`uinteger`
Uint64	✅ Yes	`ubigint`
Union	✅ Yes	`varchar`

Notes #

DuckDB supports native unsigned integer types (uinteger, ubigint)
List types are converted to DuckDB arrays with the appropriate element type (e.g., integer[])
Date32 and Date64 types are both mapped to timestamp for compatibility
UUID and JSON types have native DuckDB support

† Complex types like Struct and Map are converted to varchar for storage, losing their structured nature
