Overview #

ClickHouse destination plugin

This destination plugin lets you sync data from a CloudQuery source to ClickHouse database.

It supports append write mode only. Write mode selection is required through write_mode.

Supported database versions: >= 24.8.1

Configuration #

Example #

kind: destination
spec:
  name: "clickhouse"
  path: "cloudquery/clickhouse"
  registry: "cloudquery"
  version: "v7.3.5"
  write_mode: "append"
  send_sync_summary: true
  # Learn more about the configuration options at https://cql.ink/clickhouse_destination
  spec:
    connection_string: "clickhouse://${CH_USER}:${CH_PASSWORD}@localhost:9000/${CH_DATABASE}"
    # Optional parameters
    # cluster: ""
    # ca_cert: ""
    # engine:
    #   name: MergeTree
    #   parameters: []
    #
    # batch_size: 10000
    # batch_size_bytes: 5242880 # 5 MiB
    # batch_timeout: 20s

This example configures a ClickHouse instance, located at localhost:9000. It expects CH_USER, CH_PASSWORD and CH_DATABASE environment variables to be set. The (top level) spec section is described in the Destination Spec Reference.

Make sure you use environment variable expansion in production instead of committing the credentials to the configuration file directly.

ClickHouse spec #

This is the (nested) spec used by the ClickHouse destination plugin.

connection_string (string) (required)
Connection string to connect to the database. See SDK documentation for more details.
Example connection string:
- "clickhouse://username:password@host1:9000,host2:9000/database?dial_timeout=200ms&max_execution_time=60"
cluster (string) (optional) (default: not used)
Cluster name to be used for distributed DDL. If the value is empty, DDL operations will affect only the server the plugin is connected to.
ca_cert (string) (optional) (default: not used)
PEM-encoded certificate authorities. When set, a certificate pool will be created by appending the certificates to the system pool.
See file variable substitution for how to read this value from a file.
engine (optional, table engine settings. Default: MergeTree engine)
Engine to be used for tables. Only *MergeTree family is supported at the moment.
batch_size (integer) (optional) (default: 10000)
Maximum number of items that may be grouped together to be written in a single write.
batch_size_bytes (integer) (optional) (default: 5242880 (= 5 MiB))
Maximum size of items that may be grouped together to be written in a single write.
batch_timeout (duration) (optional) (default: 20s)
Maximum interval between batch writes.
partition (optional, partitioning) (default: no partitioning)
Partitioning strategy to be used for tables (i.e. PARTITION BY clause in CREATE TABLE statements).
order (optional, ordering) (default: use existing primary key)
Ordering strategy to be used for tables (i.e. ORDER BY clause in CREATE TABLE statements).

ClickHouse table engine

This option allows to specify a custom table engine to be used.

name (string) (required)
Name of the table engine. Only *MergeTree family is supported at the moment.
parameters (array of parameters) (optional) (default: empty)
Engine parameters. Currently, no restrictions are imposed on the parameter types.

kind: destination
spec:
  name:       "clickhouse"
  path:       "cloudquery/clickhouse"
  registry:   "cloudquery"
  version:    "v7.3.5"
  write_mode: "append"
  send_sync_summary: true

  spec:
    connection_string: "clickhouse://${CH_USER}:${CH_PASSWORD}@localhost:9000/${CH_DATABASE}"
    engine:
      name: ReplicatedMergeTree
      parameters:
      - "/clickhouse/tables/{shard}/{database}/{table}"
      - "{replica}"

Partitioning

This option allows you to specify a partitioning strategy to be used for tables. It is an array of objects.

Each object has the following fields:

tables (array of strings) (optional) (default: ["*"])
List of glob patterns to match table names against. Follows the same rules as the top-level spec tables option.
If a table matches both a pattern in tables and skip_tables, the table will be skipped.
Partition strategy table patterns should be disjointed sets: if a table matches two partition strategies, an error will be raised at runtime.
skip_tables (array of strings) (optional) (default: empty)
List of glob patterns to skip matching table names against. Follows the same rules as the top-level spec skip_tables option.
If a table matches both a pattern in tables and skip_tables, the table will be skipped.
Partition strategy table patterns should be disjointed sets: if a table matches two partition strategies, an error will be raised at runtime.
skip_incremental_tables (boolean) (optional) (default: false)
If set to true, incremental tables will not be partitioned by this strategy.
partition_by (string) (required)
Partitioning strategy to use, e.g. toYYYYMM(_cq_sync_time), the string is passed as is after "PARTITION BY" clause with no validation or quoting.
An unset partition_by is not valid.

Example:

partition:
- tables: ["*"]
  skip_tables: ["special_partition_table", "non_partitioned_table"]
  partition_by: "toYYYYMM(_cq_sync_time)"
- tables: ["special_partition_table"]
  partition_by: "toYYYYMMDD(_cq_sync_time)"

Ordering

This option allows you to specify custom ORDER BY clauses for tables or groups of tables. It is an array of objects.

Each object has the following fields:

tables (array of strings) (optional) (default: ["*"])
List of glob patterns to match table names against. Follows the same rules as the top-level spec tables option.
If a table matches both a pattern in tables and skip_tables, the table will be skipped.
Ordering strategy table patterns should be disjointed sets: if a table matches two ordering strategies, an error will be raised at runtime.
skip_tables (array of strings) (optional) (default: empty)
List of glob patterns to skip matching table names against. Follows the same rules as the top-level spec skip_tables option.
If a table matches both a pattern in tables and skip_tables, the table will be skipped.
Ordering strategy table patterns should be disjointed sets: if a table matches two ordering strategies, an error will be raised at runtime.
order_by (array of strings) (required)
Sort key to use, the strings are passed as is after "ORDER BY" clause with no validation or quoting.

Example:

order:
- tables: ["aws_ec2_instances"]
  order_by:
  - "`account_id`"
  - "`region`"
  - "toYYYYMM(`_cq_sync_time`) DESC"
  - "`_cq_id`"

Table TTLs

This option allows you to specify a TTL strategy to be used for tables. It is an array of objects.

Each object has the following fields:

tables (array of strings) (optional) (default: ["*"])
List of glob patterns to match table names against. Follows the same rules as the top-level spec tables option.
If a table matches both a pattern in tables and skip_tables, the table will be skipped.
TTL strategy table patterns should be disjointed sets: if a table matches two TTL strategies, an error will be raised at runtime.
skip_tables (array of strings) (optional) (default: empty)
List of glob patterns to skip matching table names against. Follows the same rules as the top-level spec skip_tables option.
If a table matches both a pattern in tables and skip_tables, the table will be skipped.
TTL strategy table patterns should be disjointed sets: if a table matches two TTL strategies, an error will be raised at runtime.
ttl (string) (required)
TTL interval to use, relative to _cq_sync_time. E.g. INTERVAL 60 DAY, the string is passed as-is after a "TTL _cq_sync_time + " clause with no validation or quoting.

Example:

ttl:
- tables: ["*"]
  skip_tables: ["no_ttl_table"]
  ttl: "INTERVAL 60 DAY"

Connecting to ClickHouse Cloud #

To connect to ClickHouse Cloud, you need to set the secure=true parameter, username is default, and the port is 9440. Use a connection string similar to:

    connection_string: "clickhouse://default:${CH_PASSWORD}@<your-server-id>.<region>.<provider>.clickhouse.cloud:9440/${CH_DATABASE}?secure=true"

See Quick Start: Using the ClickHouse Client for more details.

Verbose logging for debug

The ClickHouse destination can be run in debug mode. To achieve this pass the debug=true option to connection_string. See SDK documentation for more details.

Note: This will use SDK built-in logging and might output data and sensitive information to logs. Make sure not to use it in production environment.

kind: destination
spec:
  name:       "clickhouse"
  path:       "cloudquery/clickhouse"
  registry:   "cloudquery"
  version:    "v7.3.5"
  write_mode: "append"
  send_sync_summary: true

  spec:
    connection_string: "clickhouse://${CH_USER}:${CH_PASSWORD}@localhost:9000/${CH_DATABASE}?debug=true"

Types #

Apache Arrow type conversion #

The ClickHouse destination plugin supports most of Apache Arrow types. It uses the same approach as documented in ClickHouse reference. The following table shows the supported types and how they are mapped to ClickHouse data types.

Unsupported types are always mapped to String.

Arrow Column Type	ClickHouse Type
Binary	String
Binary View	String
Boolean	Bool
Date32	Date32
Date64	DateTime
Decimal128 (Decimal)	Decimal
Decimal256	Decimal
Fixed Size Binary	FixedString
Fixed Size List	Array
Float16	Float32
Float32	Float32
Float64	Float64
Int8	Int8
Int16	Int16
Int32	Int32
Int64	Int64
Large Binary	String
Large List	Array
Large String	String
List	Array
Map	Map
String	String
String View	String
Struct	Tuple
Time32	DateTime64
Time64	DateTime64
Timestamp	DateTime64
UUID (CloudQuery extension)	UUID
Uint8	UInt8
Uint16	UInt16
Uint32	UInt32
Uint64	UInt64

Nested ClickHouse types have their values converted according to the aforementioned rules.
